FEATURES
513 kWh CATL battery for full-route operation
This 6×4 electric garbage compactor truck runs on a 513 kWh CATL battery pack, built for long collection routes and landfill round trips. Average energy consumption is 1.2 kWh/km (empty and full averaged, driving only), so fleet managers can plan routes and charging with clear numbers.
Four-motor drive with 720 kW peak power
The electric garbage compactor truck uses four motors and a dedicated electric drive axle. The 6×4 configuration delivers strong, steady power on mixed flat and hilly roads, even when fully loaded and heading to the landfill.
33 kW electric compaction system
This electric garbage compactor draws 33 kW while parked and compacting, powered directly from the battery. There is no diesel engine idling, so operation is quieter and cleaner in residential areas. Compaction energy is separate from the 1.2 kWh/km driving figure, which makes energy budgeting more accurate.
Multi-layer electrical safety protection
The body is rated IP68 and the battery IP69K, giving strong protection against water, dust and high-pressure washing. Full-circuit high-voltage interlock adds another safety layer, making this electric garbage compactor truck dependable for daily sanitation work.
Heavy-duty double-layer frame with extra-long wheelbase
The double-layer frame and extra-long wheelbase are designed to carry a large 25-cubic-yard compactor body and a heavy battery pack. The 6×4 electric garbage compactor truck stays stable through sharp turns and changing altitudes, with better load distribution and long service life.
SPECIFICATIONS
Product Model | 6×4 Electric Garbage Compactor Truck |
Overall Dimensions | 10444×2550×3600mm |
Wheelbase | 4325+1350mm |
GVW | 25000Kg |
Drive Mode | 6×4 4 Electric Motors |
Power Battery | CATL Lithium‑iron‑phosphate Battery |
Battery Capacity | 513kWh |
Rated / Peak Motor Power | 320 / 720 kW |
The above mentioned figures are approximate.
