FEATURES
8×4 Heavy-Duty Chassis
Kyokuto original penetrated cross member structure improves impact resistance and high durability.
300 m² Diaphragm Filter Press
The 8×4 Sludge Dewatering Truck is equipped with a 300 m² high-pressure diaphragm filter press for efficient solid-liquid separation and sludge dewatering under high-pressure filtration.
High-Pressure Sludge Dewatering
The Sludge Dewatering Truck uses high-pressure filtration and squeezing to separate water from sludge, helping produce a drier sludge cake and reduce the volume of material requiring further handling.
Automatic Chemical Dosing System
The Sludge Dewatering Truck integrates an automatic chemical dosing system to support sludge conditioning before the filtration process, helping improve the efficiency of solid-liquid separation.
Integrated Secondary Squeezing System
The 8×4 Sludge Dewatering Truck features a secondary squeezing system for additional pressure treatment after initial filtration, supporting further water removal from the sludge cake.
Mobile and Ready for On-Site Operation
The 8×4 Sludge Dewatering Truck integrates feeding, filtration, control, and discharge equipment into one mobile unit, reducing dependence on permanent civil infrastructure and making it suitable for flexible multi-site operations.
SPECIFICATIONS
QUIPMENT/VEHICLE | Sludge Dewatering Truck |
Product Model | 300 CBM Sludge Dewatering Truck |
Overall Dimensions | 12600x2550x3980 mm |
GVW | 31000 kg |
Wheelbase | 1850+4600+1350 mm |
Drive Type | 8×4 |
Engine | Yuchai |
Horsepower | 350 hp |
