FEATURES
Pure Electric Power
The Electric Sealed Bin Garbage Truck features a 70.47 kWh battery and a driving range of up to 340 km, providing efficient and eco-friendly operation for urban sanitation.
Hydraulic Bin Loading System
Equipped with a hydraulic rear loading platform, the garbage truck can lift, turn and unload garbage bins efficiently, reducing manual labor and improving collection efficiency.
Fully Sealed Garbage Body
The sealed body helps prevent garbage leakage, scattered waste and unpleasant odors during transportation, reducing secondary pollution.
Low-Noise Operation
With a pure electric drive, this Electric Sealed Bin Garbage Truck produces low operating noise and zero tailpipe emissions, making it suitable for daytime and nighttime waste collection.
SPECIFICATIONS
ELECTRIC SEALED BIN GARBAGE TRUCK BASIC INFORMATION | |
Overall Dimension | 5890×1910×2230 mm |
Curb Weight | 2300 Kg |
GVW | 3495 Kg |
Rated Payload | 1065 Kg |
Wheel Base | 3800 mm |
Front/Rear Overhang | 715/1375 mm |
Maximum Speed | 80 km/h |
Peak Power | 105 kW / 142 PS |
Battery Capacity | 70.47 kWh (CATL ) |
Range | 340 km |
Cargo Box Size | 3700×1900×1370 mm |
Tyre Size | 185R14LT 6PR |
Fuel Type | Pure Electric |
The above mentioned figures are approximate.
